Flir E5 PRO Thermal Imaging Camera

FLIR E5 PRO

Ask a question about this product

PRODUCT DESCRIPTION

The FLIR E5 Pro is your must-have tool for locating and diagnosing electrical, mechanical, and building problems. Quickly pinpoint hot spots and easily identify problems with vibrant thermal imagery supported by FLIR-patented MSX® (Multi-Spectral Dynamic Imaging) enhancement.

Your inspections will be more efficient because you can do all your work from the touchscreen: organize your photos, add detailed notes, and upload them directly to the FLIR Ignite cloud for convenient access from any device. When you’re ready to share images and create client reports, your images and notes are already available in FLIR Ignite or FLIR Thermal Studio for the most streamlined experience.

  • QUICKLY IDENTIFY PROBLEMS

    FLIR-patented MSX® (Multi-Spectral Dynamic Imaging) enhancement provides highly detailed thermal images to help you quickly recognize where a problem is located.

  • DO IT ALL FROM THE TOUCHSCREEN

    Organize your photos, add detailed notes, and upload them directly to the FLIR Ignite cloud for convenient access from any device.

  • STREAMLINE SHARING AND REPORTING

    Share images easily and create advanced client reports in FLIR Ignite or FLIR Thermal Studio.

Specifications

Model Number

FLIR E5 PRO

Imaging and Optical Data

IR Resolution

160 × 120 (19,200 pixels)

MSX Resolution

160 x 120

Thermal Sensitivity

<0.06°C (0.11°F) / <60 mK at 30°C (86°F)

Field of View

33°

Focus

Fixed Focus

Detector

Uncooled Microbolometer

Screen

3.5",  640 × 480 colour LCD

Frame Rate

9 Hz

Analysis

Image Modes

Thermal MSX, Thermal, Picture-in-Picture, Thermal blending, Digital camera



Multi-Spectral Dynamic Imaging (MSX)

IR image with enhanced detail presentation

Picture-in-Picture

IR area on the image

Temperature Range

-20°C to 550°C (-4°F to 1022°F) in two ranges

Accuracy

±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F)

Spot Meter

Centre spot; box with min/max

Alarm

Blue below or red above set temperature

Emissivity Correction

Variable from 0.1 to 1.0

Set-Up

Colour Palettes

Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC

Set-up Commands

Local adaptation of units, language, date and time formats

Image Storage

Storage Capacity

Internal memory and onboard FLIR Ignite™ cloud connectivity (with Wi-Fi)

Storage Mode

Simultaneous storage of images in IR, visual and MSX

File Formats

Standard JPEG, 14-bit measurement data included

Other

Battery Type / Op Time

 Rechargeable Lithium-ion battery / ~4 hours

Dimensions / Weight

 385 mm × 165 mm × 315 mm (15.2 in × 6.5 in × 12.4 in) / 575 grams (1.27ibs)

Drop

 2 meter / 6.6 ft

Warranty

2-Year Tool Warranty - 10-Year Sensor Warranty
